Technical parameters:
- Material: high quality homogenous TPU material;
- Color: A variety of colors are available, such as white, blue, red, etc.;
- Thickness: generally 0.8mm-2.0mm, different thicknesses can also be customized according to your needs;
- Width: generally 200mm-2000mm, different widths can also be customized according to your needs;
- Tensile strength: generally 15-25MPa, different tensile strengths can also be customized according to your needs;
- Pressure resistance: Generally 10-20MPa, different pressure resistance can also be customized according to your needs;
- Tensile resistance: generally 400%-600%, different tensile properties can also be customized according to your needs;
- Wear resistance: generally 2-3 mm³, different wear resistance can also be customized according to your needs;
- Corrosion resistance: It has good corrosion resistance and can resist corrosive substances such as acid, alkali, oil, etc.;
- High temperature resistance: Able to work normally in the temperature range of 50℃-120℃;
- Stretch recovery rate: generally 50%-70%. Different stretch recovery rates can also be customized according to your needs;
- Density: 1.2-1.25g/cm³.
Product features:
Made of high quality TPU material, meets food grade hygiene standards, has no smell, and is safe and reliable.
Homogeneous structure design has excellent wear resistance, corrosion resistance, high temperature resistance, oil resistance, etc., and has a long life.
The surface is smooth and flat, easy to clean and maintain.
It has excellent tensile strength, pressure resistance and tensile resistance, and is suitable for high-speed conveying and carrying heavy loads.
The colors are bright, and conveyor belts of different colors, thicknesses, widths and lengths can be customized according to your needs.
Product application:
This product is widely used in the production and processing process of meat and pet food. It is mainly used for the transportation and transmission of various types of meat and pet food in the production and processing process, including:
Transportation of meat products such as ham, bacon, sausage, luncheon meat, cooked food, etc.;
Processing, packaging, transportation and other aspects of pet food;
Sorting, cleaning, cutting, grilling, and smoking of all kinds of meat and pet food.
Things to note:
This product is suitable for food processing industries such as meat and pet food, and is not suitable for other industries;
Please carefully inspect the surface of the conveyor belt before use to ensure no obvious wear, scratches or damage;
Please be careful to prevent the conveyor belt from coming into contact with hard objects during use to avoid damage;
During use, if you find abnormalities or increased wear and tear on the conveyor belt, please replace or repair it promptly to ensure production efficiency and quality.
Homogenous TPU Nutritional Belt for Meat, Pet Food Industry is made of high-quality TPU materials, meets food grade hygiene standards, has no smell, and is safe and reliable. At the same time, its surface is smooth and flat, easy to clean and maintain, and can withstand heavy loads and high speed transportation work. Furthermore, it is brightly colored, and conveyor belts of different colors, thicknesses, widths, and lengths can be customized according to your needs.
Troubleshooting and troubleshooting
Conveyor belt oil spill: An oil spill from the conveyor belt may be caused by improper connection or compression at the conveyor belt connection.
Solution: Check whether the conveyor belt connection is firmly connected and whether there is any looseness or oil leakage. If there is looseness, it needs to be reconnected and tightened to ensure that it is secure and reliable.
Conveyor belt fracture: The conveyor belt may break during use, possibly due to excessive stretching, heavy load, or aging.
Solution: Check whether the load of the conveyor belt is too heavy and exceeds its carrying capacity. If it is exceeded, the load needs to be reduced or the conveyor belt with a larger bearing capacity needs to be replaced. Also, if the conveyor belt is old or used for too long, it also needs to be replaced in time.
Conveyor belt deviation: The conveyor belt may deviate during operation, possibly due to uneven belt tension, uneven installation, or unbalanced conveying objects.
Solution: Check whether the conveyor belt tension is uniform, whether it meets the requirements, and adjust the tension. At the same time, check whether the installation of the conveyor belt is smooth and stable. If it is not flat, it needs to be reinstalled. Also, it is necessary to check whether the conveying object is balanced. If balance is needed, the position of the object must be adjusted or balanced using a regulator.
Conveyor belt slippage: The conveyor belt may slip, possibly due to wear on the surface of the conveyor belt, insufficient lubrication, or excessive load.
Solution: Check whether the surface of the conveyor belt is worn. If wear is worn, it needs to be replaced in time. At the same time, check whether the conveyor belt is sufficiently lubricated. If not enough, lubrication or oil is required. Also, if the load is too heavy, it is necessary to reduce the load or replace the conveyor belt with a higher load capacity.
Shunsheng Homogenous TPU Nutritional Belt for Meat, Pet Food Industry is suitable for food processing industries such as meat and pet food, including large meat processing plants, pet food manufacturers, meat split processing enterprises, etc. You can choose this product as a conveyor belt for your production line to improve production efficiency and product quality.
